AVS460 (AUTO-TILT) Specifications

Video Sensor

1/2 inch  CCD

Horizontal Resolution

>470 lines

Minimum Illumination

2.5 lux (F1.6)

Signal to Noise Ratio

>48 dB

Lenses, 1/2 inch format

24  mm,  F3.1,  (Telephoto)      11.5ºx15.3º

15  mm,  F2.0,  (Standard)        18.4ºx24.4º

7.5 mm,  F1.6,  (Wide Angle)    36.4ºx45.2º

Video Output, 1.0 VP-p/75 ohms

Composite Video                     - BNC

Y/C, S-VHS Super Video          - 4Pin

RGB                                         - 15 Pin D-sub
PAL Optional

Scan Area

768(H) x 494(V)  Effective Pixels

Scanning System

2:1 interlace

Synchronization

Internal/External  (Auto Switching)

White Balance

Auto Tracking

Gain Control

AGC: Automatic Gain Control

Electronic Shutter

Auto:       1/60   -  1/10,000 second

Controls

ON/OFF

Servo

56 oz./inch torque

3 self-adjusting attitude positions for taxi, take-off and landing, with remote programming and manual override

Power Requirement

Regulated +28 or +12 VDC / 1 Amp

2, 5, 10, 15, 20, or 30 Meters

(6.6, 16.5, 33, 49.5, 66, or 99 Feet)

DO-160D Tested

Section 15, 20 & 21 Category A T & Z

STC'ed in

(Supplemental Type Certificate)

Falcon 50 & 900         Citation VII

Challenger 601          BAe 800 & 1000

Gulfstream IV            B707,737 & MD80
